SD CARD PLAYER / RECORDER BLACKMAGIC HYPERDECK STUDIO MINI 4K – 6G SDI 2 X 128GB

Blackmagic Design’s HyperDeck Studio Mini is a portable broadcast quality record/playback deck that can also be rackmounted. It features a 6G-SDI input that allows capturing video up to 2160p30, and it incorporates one HDMI and two 6G-SDI outputs. It records to two SD card slots, which enable virtually endless recordings. You can also control the unit using either the USB port or over Ethernet via the RJ-45 connector. An integrated LCD on the front panel allows you to monitor the video.

Specifications:

• Video Input: 6G-SDI: 1 x BNC
• Video Output: 6G-SDI: 2 x BNC + HDMI: 1 x HDMI (type A)
• Audio Input: None (embedded audio only 16 channel)
• Audio Output: None (embedded audio only 16 channels SDI, 8 channels HDMI)
• Input Connector: 1 x BNC
• Output Connector: 1 x BNC
• Device Control: Ethernet 1 x RJ-45 for remote operation + Computer Interface 1 x USB-C connector for software updates and HyperDeck Utility
• 2 x SD slots for SD, HD and UHD recording
• Supported Resolutions:

  4K
  3840 x 2160p: 30/29.97/25/24/23.98

  HD
  1920 x 1080p: 60/59.94/50/30/29.97/25/24/23.98
  1920 x 1080i: 60/59.94/50
  1280 x 720p: 60/59.94/50

  SD
  NTSC
  PAL

• SDI Compliance:
  SMPTE 259M/292M/296M/425M

• SDI Metadata Support: HD RP188 and closed captioning

• Supported Codecs:
  Apple ProRes 422 HQ QuickTime
  ProRes 422 QuickTime
  ProRes 422 LT QuickTime
  ProRes 422 Proxy QuickTime
